Direct Answer
The 53cm and 71cm figures describe gantry spans, not finished cabinet dimensions or a guaranteed prize-size limit. Choose the kit that fits your cabinet's internal space, mounting points, travel clearance, planned prizes, and service access. Either size can be considered for a commercial build when the cabinet and components are properly matched; 71cm is not automatically the right choice just because the site earns revenue.
Compare the Standard Sets
| What to compare | 53cm Standard Set | 71cm Standard Set |
|---|---|---|
| Gantry span | 53cm | 71cm |
| Gantry material in the current Standard Set listing | Stainless steel | Chrome steel |
| Cabinet fit | Check internal width, mounting, travel and service space | Check internal width, mounting, travel and service space |
| Cabinet tracks / guide rails | Not included; supply rails matched to your cabinet | Not included; supply rails matched to your cabinet |
| Power and included components | Refer to this exact edition's product specification | Refer to this exact edition's product specification |
| Prize compatibility | Check actual cabinet, claw and prize chute | Check actual cabinet, claw and prize chute |
These material entries describe the linked Standard Sets only, not every 53cm or 71cm edition. See the 53cm Standard Set and 71cm Standard Set for their current included components and power-supply input specifications.
Measure the Cabinet, Not Just the Gantry
Before ordering, measure the cabinet's usable internal width and depth, mounting points, carriage travel, prize field, chute, door access, and space for wiring and service. A wider gantry can offer more horizontal reach in a suitable cabinet, but it does not alone establish floor footprint or how many prizes will fit. All DIY kits require the builder to supply cabinet tracks or guide rails sized for the chosen cabinet; a kit is not a complete enclosure.
For prizes, test size, shape, weight, and surface against the actual claw, usable travel, cabinet clearance, and chute. Do not assume that all 53cm builds accept only prizes below 20cm or that every 71cm build accommodates 35cm-plus plush toys.
Edition and Material Differences
Hiclawcrane currently lists a 53cm Stainless Steel Standard Set and several 71cm editions. The 71cm Standard Set uses chrome steel, while the 71cm Complete Set is a stainless steel configuration. Check each listing rather than assuming material follows size alone.
- 71cm Classic Mainboard Edition
- 71cm LCD Mainboard Edition
- 71cm Bill Acceptor Edition
- 71cm Custom Music Edition
The Custom Music Edition's music-upload function is available on a single kit; OEM customization of complete machines or kits begins at 20 units. A different board, payment accessory, or prize sensor must be confirmed from that edition's listing rather than assumed from gantry size.
Which Size Should You Choose?
Start with the cabinet you can build or service, then compare the gantry, prize field, payment options, board, included parts, and budget. A smaller venue can use a 71cm build if there is adequate space; a commercial operator may choose 53cm when its cabinet and prizes suit the site. For complete machines and DIY kits, one unit can be ordered, wholesale pricing starts at six, and customization starts at twenty. Parts follow their own quantities and quotation terms.
Frequently Asked Questions
What is the difference between a 53cm and 71cm gantry?
The numbers identify different gantry spans. A 71cm assembly needs a suitably sized cabinet and can provide wider horizontal reach, but neither number alone determines finished cabinet size or prize capacity.
Which size is better for a commercial venue?
Neither size is automatically better. Check available space, cabinet dimensions, planned prizes, service access, budget, and the specific kit edition. A 53cm build may suit a commercial location; a 71cm build needs adequate room and compatible components.
Can I upgrade a 53cm build to a 71cm gantry later?
Do not assume it is a direct swap. Confirm cabinet internal space, mounting points, tracks or rails, travel clearance, power supply, board, wiring, and other part compatibility before planning an upgrade. Choosing the intended size before building is simpler than promising an unverified conversion.
What prizes fit each size?
Check the actual claw, cabinet clearance, travel path, and prize chute with the prizes you intend to use. Gantry span alone does not give a universal maximum prize dimension.
