Even well-maintained claw machines develop faults over time. This guide covers the most common problems arcade operators encounter, how to diagnose them, and how to fix them quickly to minimize downtime.
Fault 1: Claw Won't Move
Symptoms: Joystick input has no effect. Claw stays in home position.
- Check joystick wiring connection to the control board
- Test joystick with a multimeter — replace if faulty
- Check motor driver output on the PCB
- Inspect X/Y axis motors for burnt smell or no response
Fault 2: Claw Drops But Won't Grip
Symptoms: Claw descends correctly but fingers don't close, or close with no strength.
- Check claw solenoid wiring
- Test solenoid with direct 12V — if no response, replace solenoid
- Check claw strength setting in operator menu (may be set too low)
- Inspect claw spring for wear or breakage
Fault 3: Machine Won't Accept Coins
Symptoms: Coins are rejected or machine doesn't register credits.
- Clean coin acceptor sensors with compressed air
- Recalibrate coin acceptor with a fresh reference coin
- Check signal wire connection from coin acceptor to PCB (COIN terminal)
- Test coin acceptor with direct power — replace if unresponsive
Fault 4: Machine Powers On But Display Is Blank
Symptoms: Power LED is on but score display or LCD shows nothing.
- Check display wiring connection to control board
- Verify +5V supply to display is within spec (use multimeter)
- Check for blown fuse on display circuit
- Replace display if wiring and power are confirmed good
Fault 5: Claw Returns to Wrong Home Position
Symptoms: After a play, claw doesn't return to the correct starting position.
- Check X/Y axis limit switches — clean or replace if faulty
- Inspect limit switch wiring for loose connections
- Check home position settings in operator menu
Fault 6: Machine Resets Mid-Game
Symptoms: Machine restarts unexpectedly during play.
- Check power supply output voltage — low +5V is the most common cause
- Inspect all wiring for loose connections or shorts
- Check for overheating on the control board
- Replace power supply if voltage is unstable
Fault 7: LED Lighting Not Working
Symptoms: Interior or exterior LEDs are off or flickering.
- Check LED strip wiring connections
- Test LED controller output
- Replace faulty LED strip sections
- Check fuse on LED circuit
Fault 8: Prize Chute Door Won't Open
Symptoms: Player wins but prize door doesn't open.
- Check prize door solenoid wiring
- Test solenoid with direct 12V
- Check prize sensor
- Inspect door mechanism for physical obstruction
Diagnostic Tools You Need
- Multimeter: Essential for checking voltages and continuity
- Compressed air: For cleaning sensors and coin paths
- Spare fuses: Multiple ratings — always check fuses first
- Spare coin acceptor: Swap-test to isolate coin acceptor faults quickly
Frequently Asked Questions
How do I reset my claw machine control board?
Most control boards reset by powering off for 30 seconds and powering back on. For a full factory reset, hold the service button while powering on.
My machine worked fine yesterday but won't start today. What should I check first?
Check the fuse first — it's the most common cause of sudden failure. Then check power supply output voltage.
Where can I get a replacement control board?
Hiclawcrane supplies replacement control boards for most claw machine models. Contact us with your board model number for availability and pricing.
